Black Diamond Log Splitter 25 Tonne Tractor 3 Point Linkage

Tackle tough timber with ease using the Black Diamond 3 Point Linkage Log Splitter – a cost-effective, engine-free solution that harnesses the power of your tractor’s hydraulics.

Built with a heavy-duty steel 3 point linkage frame, this splitter is designed to go wherever your tractor can, allowing you to split wood anywhere on your property. Engineered to handle even the hardest Australian hardwoods, it delivers impressive ramming force and includes a reinforced end plate for added durability.

Offering both horizontal and vertical operation, this splitter gives you flexibility in the field. If your log is too heavy to lift, simply switch to the vertical position and split directly on the ground.

Black Diamond 3PL splitters have the following features:
• 8” 200mm Steel Wedge
• Log Stripper
• 25 Tonne Ram

• SPECIFICATIONS
• Model LS25-3PT
• Comes Complete With Hydraulic Hoses With Male Poppets (One Set Of Rear Remotes Is Required)
• Ram Has Large 4.13″ Cylinder With 26″ Or 650mm Stroke
• 8” 200mm Heavy Duty Steel Wedge
• Steel Beam with Built In Log Cradle
• Two Easy Steps From Splitting Horizontal to Vertical Position
• Hydraulic Ram Can Be Stopped At Any Stage During Splitting Cycle
• Automatic Return Valve
• Conveniently Mounted Hydraulic Control Valve
• Minimum Oil flow required: 19lt per minute
• Minimum Psi required: 1500psi
• Maximum Psi 3200
• Cat 1 Linkages
• Maximum Log Length 650mm
• Powder Coated Finish
• Unit Weight Approx 190kg
• Shipping Weight Approx 220Kg
• 12 Months Parts Warranty

This 3 Point Linkage Log Splitter is designed for tractors with an oil flow of 30-57Litres Per Minute (8-15 Gallons) at 1500-2500Psi.

Note: Exceeding the recommended pressure rating of 3200 Psi will void warranty.
